JA Solar JAM72S30-550W Deep Bue 3.0 Series Solar Panel

AED 0.00
In stock
Product Model
JAM72S30550W
JA Solar Deep Blue 3.0 Series is asssembled with 11BB PERC Cells,  the half-cell configuration of the modules offers the advancetages of higher power output, better termperature-dependent performance, reduced sharing effect on the energy generation. Lower risk of hot-spot, as swell as enhanced tolerance for mechanical loading.
Main Features

1) Advance MBB Half Cell Module.
2) Higher Output power.
3) Less shading and lower resistive loss.
4) Lower LCOE.
5) Better Mechanical loading tolerance
More Information
Technical specification
Model Product
JAM72S30-530W
JAM72S30-540W
JAM72S30-550W
Module type
 JAM72S30-530W  JAM72S30-540W JAM72S30-550W
Testing Condition
STC      NOCT   STC      NOCT STC      NOCT
Max Power (Pmax/W)
530       401   540     408.0   550     416
Open Circuit Voltage (Voc/V)
 49.30   46.18   49.60   46.43  50.02      46.85
Short Circuit Current (Isc/A)
13.72    11.01  13.86     11.09  14.07      11.21
Voltage at Max Power (Vamp/V)
41.31    38.57   41.64    38.99  41.96    39.43
Current  at Max Power (Imp/A)
 12.83     10.39 12.97    10.47  13.11     10.55
Module Efficiency
 20.5  20.9 21.30


Operating Parameters



Operational Temp
 -40°C ~ +85°C -40°C ~ +85°C  -40°C ~ +85°C
Power Output Tolerance
 0~+5W 0~+5W   0~+5W
Voc and Isc Toleraance
 ±3%  ±3%  ±3%
Max system volage
 DC1500V (IEC/UL)  DC 1500V (IEC/UL) DC 1500V (IEC/UL)
Max Series Fuse rating
25A   25A 25A
Nominal Operating Cell Temp
 45±2°C  45±2°C  45±2°C
Protectional Class
 Class II Class II Class II
Fire Rating
 UL type 1 or 2 UL type 1 or 2  UL type 1 or 2
Dimension
2278x1134x30
2278x1134x30
2278x1134x30
Weight
27.3 kg
27.3 Kg
27.3 Kg
Packaging
36 pcs/ pallet

720 pcs per 40HC
36 pcs / pallet

720 pcs per 40HC
36 pcs / pallet

720 pcs per 40HC



Disclaimer
1. Astel Digicom Electronics reserves the right to change, modify specifications without prior notice.
2. All pictures are for illustrative purposes only. Actual product may be different in color and size, which may appear in product specifications.
3. Every effort is made to provide accurate information at the time of publishing, however Astel Digicom Electronics LLC is not responsible for
any loss, directly or indirectly caused by any error in publishing.
4. E&OE (Errors and Omissions are excepted)
5. Longi is registered trade mark of Longi, China. Longi  registered office No 8369, Shengyuan Road, Xi'an Economic and Technological Development Zone, Xi'an, China
6. Specifications included in this datasheet are subject to change without notice . Longi reserves the right of final interpretation.
