Astel newest model of V2F-5MP Series is suitable for AHD/TVI/CVI 5MP Cameras which require very high performance analog to digital conversion chipset.
ASTEL series of Video to Fiber Converter adopt the advanced digital video and optical fiber transmission technology and implement the transmission of real-time video and synchronization signals with no-distortion and high-quality video effect.
The play-and-plug design makes the installation more convenient and easier, and no user adjustments are required.
Standalone design. 8-bit digital code and non-compression video transmission. Suitable for 1MP, 2MP, 3MP, 4MP, 5MP AHD Cameras Video to fiber transmission. Suitable for 1920x1080P/30Hz, 2560x1440P/30 Hz, 2560x1920P/30 Hz video resolution transmission. 5Hz-10MHz video channel. Automatic compatible PAL, NTSC and SECAM video system. With AGC circuit, constant input optical power, and large dynamic range. GB optical fiber transmission, large capacity, and easy to upgrade. Power supply and other parameter indicators on front panel. Support no-damage regenerative trunk of video. Advanced self-adapting technology, and no user adjustments are required. Advanced lightning protection design, support 4kv lightning protection Single fiber transmission, standard 20km, optional 40km, 60km, 80km, 100km, 120km long-distance transmission.
