UTP CAT6 23AWG LSZH Jacket

AED 355.00

In stock

Product Model

UTPCAT6BCLZ305MBP

1) Astel Hi Quality UTP CAT6 Cables are manufactured from Pure Copper Conductors and HDPE. 4 Pairs are perfectly balanced providing low attenuation, high immunity from cross talk and noise shielding.

2) ASTEL UTP CAT6 cables exceed or meet Category 6 EIA/TIA 568C2 and IEC 11801 specifications. IT is tested to 300 MHz frequency range and designed to support Gigabit 1000Base-T and 1000 Base-TX applications for full length of 100m.

Details

1) Astel Hi Quality UTP CAT6 Cables are manufactured from Pure Copper Conductors and HDPE. 4 Pairs are perfectly balanced providing low attenuation, high immunity from cross talk and noise shielding.

Technical specification

More Information

Technical specification

Main Applications

1) 100Base-TX.

2) 100Base-T.

3) 100VG-AnyLAN.

4) 1000Base-T (Gigabit Ethernet).

5) 1000Base-TX.

6) ATM.

Specifications@20°C
ModelProduct	Unit	UTPCAT6BCLSZH
Construction:
Conductor	Conductor	Solid Bare Copper
Conductor OD	mm	0.55 ± 0.005
Conductor AWG		23 AWG
Insulation		HDPE
Insulation Dia	mm	1.035±0.02
Core Colours		1P-White-Blue/Blue 2P-White-Orange/Orange 3P-White-Green/Green 4 P-White-Brown/Brown
Individual Pair Shielding		NO
Plastic Separator		Yes (ROHS Compliant)
Drain Wire		NO
Outer Shielding		NIL
Outer Shielding Coverage		NIL
Jacket Material		LSZH (Flame Retardent)
Jacket Thickness		0.55±0.05
Outer Dia		6.2±0.3
Rip Cord		NO
Color		Purple
Jacket Tensile Strength	Mpa	13.5
Jacket Elongation	%	150
Bending Radius	XD	8 x OD
Packaging
Packing		NA
QTY per Box		NA
Size	cms	NA
Weight	kgs
Packing 2		305M Reel
QTY per Package		1 Reel
Size / Weight		37x37x19 / 13kgs
ElectricalandMechanical Parameters:
Impedance	Ohms/100m	100 ± 15
Frequency Range	MHz	1-300 MHz
DC Resistance for Conductor	Ohms	9.38
DC Resistance Unbalance	%	2.50%
Capacitance Unbalance to ground	pf /100m	330
Velocity of propagation	%	%
Delay Skew	ns/100m	≤45ns
Dielectric Strength	KV/min	1.0
Operating Temp Range	°C	-20 °C to +65 °C

Technical Performance (100m):
Frequency MHz	RL (≥dB)	ATT (≥dB)	NEXT (≥dB)	DELAY (≤ns)	PSNEXT (≥dB)	ELFEXT (≥dB)	PSELFEXT (≥dB)
1	20	1.9	74	570	72.3	68	65
4	23	3.7	65	552	63.3	56	53
8	24.5	5.3	60.7	546.73	48.8	49.9	46.9
10	25	5.9	59	545.38	57.3	48	45
16	25	7.5	56	543	54.2	43.9	40.9
20	25	8.4	55	542.05	52.8	42	39
25	24.3	9.5	53.3	541.2	41.3	40	37
31.25	23.6	10.6	52	540.44	49.9	38.1	35.1
62.5	21.5	15.4	47	538.55	45.4	32.1	29.1
100	20.1	19.8	44	537.6	42.3	28	25
200	18	29	40	536.54	37.8	22	19
250	17.3	32.8	38	536.27	36.3	20	17
