Astel Control and Alarm Cables are manufactured from High Purity Stranded Copper and High Flexible PVC Material. Astel Control and Alarm Cables are manufactured to IEC Standards.
Astel Control and Alarm Cables are manufactured from High Purity Stranded Copper and High Flexible PVC Material. Astel Control and Alarm Cables are manufactured to IEC Standards.
Main Features1) Multiple strand annealed bare copper twisted and compacted for more homogeneity.2) PVC Insulated 3) Twisted Pair 4) PVC jacket 5) Rated voltage: U/Uo-300V/300V 6) Working Temperature: -10 to +70°C for long duration.Main Applications1) Audio Communication, Intercom, Broadcast Sound Systems 2) Automatic Control System 3) Control signal transmission 4) For Meters, Electric Device, Automatic Door Closures 5) Any other kind of automatic low voltage devices 6) Anti Theft Alarm Systems 7) Building Intercom System 8) Building Management System 9) Compatible to IEC Standard 227 IEC 52 and 227 IEC 53
Model Product
RVVS-1x2X0.5
RVVS-1x2X1.0
RVVS-2x2x0.5
RVVS-2x2x1.0
RVVS-4x2x0.5
RVVS-4x2x1.0
Model Description
1 PAIR
2 PAIRS
4 PAIRS
Conductor
Bare Copper Stranded
Bare Copper Stranded
Bare Copper Stranded
Bare Copper Stranded
Bare Copper Stranded
Bare Copper Stranded
Conductor Structure
28x0.15
32x0.20
28x0.15
32x0.20
28x0.15
32x0.20
Insulation Diameter
1.95mm
2.50 mm
1.95mm
2.50 mm
1.95mm
2.50 mm
Conductor Cross Section Area
0.50 mm2
1.00 mm2
0.50 mm2
1.00 mm2
0.50 mm2
1.00 mm2
Conductor AWG
20 AWG
17 AWG
20 AWG
17 AWG
20 AWG
17 AWG
Insulation thickness
0.50 mm
0.60 mm
0.50 mm
0.60 mm
0.50 mm
0.60 mm
Twisting on Cores in pairs
Yes
Yes
Yes
Yes
Yes
Yes
Shielding
No
No
No
No
No
No
Overall Jacket Thickness
0.7mm
0.8mm
0.8mm
1.0mm
0.9mm
1.1mm
Overall Jacket Diameter
5.70±0.50 mm
7.20±0.50 mm
8.80±0.50 mm
10.50±0.50 mm
10.80±0.5 mm
12.60±0.5mm
Dielectric Strength
Elongation (%)
>300
>300
>300
>300
>300
>300
Tensile Strength (MPa)
>10
>10
>10
>10
>10
>10
Operation Temp °C
-20°C to +70°C
-20°C to +70°C
-20°C to +70°C
-20°C to +70°C
-20°C to +70°C
-20°C to +70°C
Electric Specifications
Dielectric Strength
1500V/5m
1500V/5m
1500V/5m
1500V/5m
1500V/5m
1500V/5m
Nominal DC Res @ 20°C (Ohms/Km)
39 Ω/Km
19.50 Ω/Km
39 Ω/Km
19.50 Ω/Km
39 Ω/KM
19.50 Ω/ KM
Insulation Resistance (M Ohms/Km)
150
150
150
150
150
150
Packing
Length each coil
100M
100M
100M
100M
100M
100M
Weight each coil 100Y
4.0 Kg
5.0 Kg
6.0 Kg
7.0 Kg
9.0 kg
12kg
Number of coils in 1 gunny bag pack
5
5
4
4
2
2
Weight of each carton (Kgs)
20.4 kgs
18.20 kgs
20.20 kgs
22.20 kgs
25.20 kgs
28.20 Kgs
Size of each carton (cms)
Notes: * DC resistance changes at the rate of 0.393% / Deg C. * Sequential meter marking on all cables. * Higher core sizes cables also available.
