TMR 200 Solid CCA Series PVC Jacket
AED 575.00
In stock
Product Model TMR-200-PVC
ASTEL 50 Ohms cables are Flexible, High Performance, Low loss communication cables designed for use in all kinds of wireless systems. ASTEL Cables are manufactured in ISO 9002 approved manufacturing plant. These cables are manufactured with latest manufacturing technologies resulting in:
High shielding effectiveness Low Intrinsic Noise Low Structural Return Loss Higher peak power rating
ASTEL 50 Ohms cables are Flexible, High Performance, Low loss communication cables designed for use in all kinds of wireless systems. ASTEL Cables are manufactured in ISO 9002 approved manufacturing plant. These cables are manufactured with latest manufacturing technologies resulting in:
High shielding effectiveness Low Intrinsic Noise Low Structural Return Loss Higher peak power rating
More Information
Technical specification
Mobile Phone Tower
GSM Towers
Cellular Base station
PCS, Paging
2 way Radio
WLL
Wireless Data
WIFI, WIMAX
Wireless Telemetry
Transmission Antenna
Microwave Antenna
Technical Specifications:
TMR-200-PVC
Construction Specification:
Item Material Diameter (mm)
Inner Conductor
Solid Copper
1.12
Dielectric
Physical Foam Polyethylene
2.95
Outer Conductor
Bonded Aluminum Foil
3.07
Overall Braid
Tinned Copper Braid
3.66
Jacket
Black PVC or Polyethylene
4.95
Electrical Characteristics
Capacitance (pF/M)
80.4
Impedance (Ohm)
50
Velocity (%)
83
Shielding Effectiveness (>dB)
90
Inner Conductor DC Resistance (Ω/km)
17.59
Outer Conductor DC Resistance (Ω/km)
16.08
Voltage Withstand (Volts DC)
1000
VSWRs (Return Loss ≥dB)
5-3000MHz
1.20 (20)
800-1000MHz
1.10 (26)
1700MHz-2000MHz
1.15 (23)
2000MHz-2400MHz
1.15 (23)
Min. Bend Radius (mm)
25
Operating Temp. (°C)
-40°C to +80°C
Packaging Information:
Gross Weight / Net Weight:
13 Kgs/ 12 Kgs
Carton Size:
29x29x 23 cms
Attenuation (Typical)
Frequency (MHz) Attenuation (≥dB/100m) Avg. Power (KW)
30
5.80
0.91
50
7.50
0.70
150
13.10
0.40
220
15.90
0.33
450
22.80
0.23
900
32.80
0.16
1500
42.40
0.12
1800
46.60
0.11
2000
49.30
0.11
2500
55.40
0.09
3000
60.20
0.09
5800
86.50
0.06
