main product photo

Satellite 8xQPSK Input to DVB-T/C Digital Transmodulator

AED 3,050.00
In stock
Product Model
DHE715X-0804
    • DHE-715X (DHE-715X-0804, DHE-715X-0808) is a Encoder Modulator and converts 8xQPSK (DVB-S/S2 Satellite inputs) signals to DVB-T/C Modulator (COFDM/QAM Modulation). It is able to receive upto 8 independent satellite (DVB-S/S2) and convert them into 4 or 8 DVB-T/C RF Channels. To make full use of the output bandwidth, we also provide the IP Input port to get more channels from the streamer or other IP sources. Its small size and excellent features makes it the ideal solution to distribute the free TV programs from satellite.
    DHE-715X (DHE-715X-0804, DHE-715X-0808) is a Encoder Modulator and converts 8xQPSK (DVB-S/S2 Satellite inputs) signals to DVB-T/C Modulator (COFDM/QAM Modulation). It is able to receive upto 8 independent satellite (DVB-S/S2) and convert them into 4 or 8 DVB-T/C RF Channels. To make full use of the output bandwidth, we also provide the IP Input port to get more channels from the streamer or other IP sources. Its small size and excellent features makes it the ideal solution to distribute the free TV programs from satellite.
    More Information
    Technical specification
    Main Features:
    1) Receive 256 IP Streams (SPTS/MPTS) over UDP or RTP.
    2) Equipped with 8x DVB-S/S2 free to air tuner.
    3) DVB-T or DVB-C Digital RF Output (User selectable).
    4) Supports all major resolutions from 480i thru 1080Px60fps.
    5) Supports CA PID Filtering, remapping, PSI/SI editing.
    6) Offers 4 or 8 continuous output channels with 4 continuous channels in row.
    7) Easy configuration with built in Web UI.
    8) Rack and wall mountable

    Technical Specifications DHE-715X
    Model Number DHE-715X-0804                DHE-715X-0808
    No of Satellite Inputs 8                                   8
    No of RF Output Channels 4                                   8
    IP input
    Input Connector 1x100/1000 <Mbps RJ45 Port
    Transport Protocol

    UDP, RTP
    Max Input IP address 256 channels
    Input Transport Stream MPTS and SPTS
    Addressing Unicast and Multicast
    IGMP Version IGMP V2 and  V3
    Satellite Input
    Input Connector 8x RF Inputs F Female, 75Ω
    Tuner number 8 Transponders
    Frequency range 950-2150 MHz
    Input level 44-84 dBuV
    DC Remote Power at RF Input 13V/18V, 22KHz/Diseqc A-B-C-D
    RF Output
    Output Connector 1x RF F Female, 75Ω
    Output carrier 4 or  8  Agile Channel
    Ouptut range 50-999.99  MHz
    Output level ≥ 45 dBmV
    Out-band rejection ≥ 60 dB
    MER Typical  38 dB
    DVB-C J.83A
    Bandwidth 6M,  7M, 8M
    Constellation 64QAM, 256WAM
    Symbol rate 3600-6960 KS/s
    DVB-C J.83B
    Bandwidth 6M,  7M, 8M
    Constellation 64QAM,  256WAM
    Symbol rate Automatically
    DVB-T
    Bandwidth 6M, 7M, 8M
    Constellation QPSK,  16 QAM,  256QAM
    Code rate 1/2,  2/3, 3/4, 5/6, 7/8
    Guard Interval 1/4, 1/8/ 1/16, 1/32
    FFT 2K, 4K, 8K
    Symbol rate 6000,  7000, 8000 KS/s
    RF Output Level ≥ 45 dBmV
    Multiplexing
    Table Supported PSI/SI
    PID Processing

    Pass-through, Remapping,

    Filtering
    Dynamic PID feature Yes
    Power supply
    Input voltage to Adapter 90~264V AC, DC 12V/ 5A
    Input frequency 50/60Hz
    Power Consumption (W) ≤49W
    Environment
    Work temperature 0°C~50°C
    Storage temperature -10°C~80°C
    Work humidity 10%~90%
    Physical characteristics
    Size(W x H x D) 482mm x 260mm x 44mm
    Net Weight <2.75Kg


    Disclaimer
    1. Astel Digicom Electronics reserves the right to change, modify specifications without prior notice.
    2. All pictures are for illustrative purposes only. Actual product may be different in color and size that may appear in product specifications.
    3. Every effort is made to provide accurate information at the time of publishing, however Astel Digicom Electronics LLC is not responsible for any loss, directly or indirectly caused by any error in publishing.
    4. E&OE (Errors and Omissions are excepted)
