RG-213U 50 Ohms Copper Center with Copper Braid

AED 1,675.00
In stock
Product Model
RG-213/U

ASTEL 50 Ohms cables are Flexible, High Performance, Low loss communication cables designed for use in all kinds of wireless systems. ASTEL Cables are manufactured in ISO 9002 approved manufacturing plant. These cables are manufactured with latest manufacturing technologies resulting in:

1) High shielding effectiveness

2) Low Intrinsic Noise

3) Low Structural Return Loss

4) Higher peak power rating

ASTEL 50 Ohms cables are Flexible, High Performance, Low loss communication cables designed for use in all kinds of wireless systems. ASTEL Cables are manufactured in ISO 9002 approved manufacturing plant. These cables are manufactured with latest manufacturing technologies resulting in:

1) High shielding effectiveness

2) Low Intrinsic Noise

3) Low Structural Return Loss

4) Higher peak power rating

More Information
Technical specification

Applications:

  1. Mobile Phone Tower
  2. GSM Towers
  3. Cellular Base station
  4. PCS, Paging
  5. 2 way Radio
  6. WLL
  7. Wireless Data
  8. WIFI, WIMAX
  9. Wireless Telemetry
  10. Transmission Antenna
  11. Microwave Antenna
Parameter RG-213/U
Inner Conductor Stranded Bare Copper
Dielectric Solid PE
Ist Outer Conductor NA
Ist Outer Conductor NA
Braid Bare Copper
Braid Coverage 97% Coverage
Braid Structure 24x8x0.12mm
Jacket Material PVC
Construction
Center Conductor Diameter 2.25mm
  (7x21AWG) (7x0.75mm)
Foam PE 7.24 mm
Ist shield NA
Jacket Diameter 10.30 mm
Nominal DCR @ 20 deg C
Inner Conductor 6.0 ohms/KM
Outer Conductor 7.20 ohms/KM
Nominal Capacitance
Impedance 50±3 ohms
Return Loss ≥22 dB
Propagation Velocity Ratio 66%
Insulation Resistance ≥2000 MΩ
Min Bending Radius (Single)
Temp Range Operation -40°C to +70°C
Temp Range Installation -20°C to +70°C
Packing
250M Reel Size 38x38x35 cms
250M Reel Weight 39 KGs
