Product Description:Ramcro R1190 is suitable Medium speed fieldbus interfaces and Balanced Digital Circuits. Maximum transmission speed 35 Mbit/second (normal use 1 or 0.5 Mbit/sec). Max. transmission distance is 1200 metres, 32 nodes per bus. Cables used have mainly 24AWG conductors, one twisted pair or multi-pair and impedance of 120 Ohm
Product Description:Ramcro R1190 is suitable for Medium speed fieldbus interfaces and balanced Digital Circuits. Maximum transmission speed 35 Mbit/second (normal use 1 or 0.5 Mbit/sec). Max. transmission distance is 1200 metres, 32 nodes per bus. Cables used have mainly 24AWG conductors, one twisted pair or multi-pair and impedance of 120 Ohm
RAMCRO ITALY R1190 DATA LAN CABLE - RS 485 - 2PR 24AWG SCREENED 300 V 75 C IEC 60332-1/UL 1581 - MAR0208HBADX-T-RB "PROD.WEEK/18" + BATCH + METER MARKING
Technical Data & Standard References
Fire Propagation:
- Test on single cable
IEC 60332-1
- Test on bunched cables
IEC 60332-3
Type of Cable:
DATA LAN RS-485 Cable
Limiting Oxygen Index (LOI)
(min 30%)
Low Voltage Directive
2014/35/UE
Smoke Density
IEC 61034
Other References:
Amount of halogen acc. to IEC 60754-1 & EN 50267-1
IEC 60754-1 (max 15%)
Acidity (ph value) and conductivity
IEC 60754-2
Sunlight resistance
UL 1581 section 1200
Notes
Electrical & Mechanical Data
Conductor Cross-section
Nom.
24 AWG
Temperature Range:
DC Resistance per core at 20° C
max Ω/km
91
During Operation
° C
-30°C up to 80°C
Insulation Resistance at 20° C
min MΩ*km
5000
During Installation
° C
-30°C up to 80°C
Nominal Mutual Capacitance
max pF/m
41
Min. Bending Radius
mm
8 x cable diameter
Inductance
max mH/km
1
Max Pulling Tension
N/mm2
41
Test Voltage - Core/Core
V
2000
Weight Approx
kg/km
66
Test Voltage - Core/Screen
V
2000
Put up length
mt
305
Operating Voltage
V
300
