main product photo

Media Converter 4 Port Ethernet to Fiber Gigabit Dual Fiber

AED 275.00
In stock
Product Model
MC-GB-4E4F-SM-DF-XX

    • E2F Media Converter

    Model: AST-MC-GB-4E4F-SM-DF-20KM

    10/100/1000Base-T to 1000Base-FX Dual Fiber Media Converters

    ASTEL MC-GB-4E4F-SM-DF series 10/100/1000 Gigabit media converter adopts swtiching technology to fulfill media conversion. It complies with IEEE 802.3az and IEEE 802.3ab standards and supports two types of media network connections. 10/100/1000BAse-T and 1000 Base-SX. ASTEL MC-GB-4E4F-SM-DF has 4 GBE RJ45 Ports and interconvert signals to 1000Base -SX. It has 2 X Dual Fiber slots and suitble for ring network.



    ASTEL- series  4 Port x 10/100/1000M Ethernet media converter adopts switching technology to fulfill media conversion. It complies with IEEE802.3z and IEEE802.3ab standards, and supports two types of media network connections: 10/100/1000Base-T and 1000Base-SX. It inter-converts electrical signals of 4x10/100/1000Base-T twisted pairs with optical signals of 2x1000Base-SX, extending the transmission distance of a network from 100m via copper cables to 20 km (SMF 9/125 um) via fiber optical cables.It supports transmission in single-mode dual fiber SM-DF mode. It has 2X Dual Fiber Slots and suitable for ring network.

    Main Features:

    1. Supporting inter-conversion between 4 x 10/100/1000 BAse-Tx and 1000Base-SX.
    2. Supporting full duplex and half duplex.
    3. Auto sensing
    4. Supporting automatic cross section of twisted pair interface, facilitating system commissioning and installation.
    5. Supporting the transmission of extra long VLAN packets.
    6. Supporting QOS and ensuing the transmission of VoIP packets.
    7. Supporting STP to form a redundant network.




    More Information
    Technical specification
    Technical specifications:
    Parameter
    AST-FO-MC-GB-4E4F-SM-DF-20KM
    Standard
    IEEE802.3ab 1000Base-T ,
    IEEE802.3z 1000Base-SX/LX Gigabit Ethernet,
    IEEE802.1qVLAN, IEEE802.1p QoS,
    IEEE802.1d Spanning Tree
     Copper Port
    Data Rate: 10/100/1000 x 4
    Connector: RJ45
    Cable type: CAT5E
    Transmission distance
    Dual Fiber Single Mode 20 Km
    Fiber Port
    Data Rate: 1000M x 2
    Distance: Single Mode Fiber: 20 KM
    SC (9/125μm)
    Wavelength: 1310 nm
    Performance
    Delay<10us
    Back plane BW: 4 Gbps
    MAC Address size: 16 Kb
    Packet Buffer size: 1 Mb
    LED indicator
    PWR (power supply),
    FX LINK (optical link action),
    TP LINK1000 (twisted pairlink1000M),
    TP LINK100 (twisted pair link 100M),
    TP ACT (twisted pair packet forwarding)
    Power
    Adapter Input AC100~220VAC
    Output  5V/1.0A, <5W
    Operating temperature
    +10ºC~55ºC
    Operating humidity
    5%~90%
    Storage temperature
    -20~65ºC
    Maintaining humidity
    5% ~ 90% non-condensing
    Dimensions
    26mm (H) * 70mm (W) * 95 mm (D)
    Adapter extra

    Disclaimer:

    Astel Digicom Electronics reserves the right to change, modify specifications without prior notice.

    All pictures are for illustrative purposes only. Actual product may be different in color and size, which may appear in product specifications.

    Every effort is made to provide accurate information at the time of publishing, however Astel Digicom Electronics LLC is not responsible for

    any loss, directly or indirectly caused by any error in publishing.

    E&OE (Errors and Omissions are excepted)
