Longi HiMo7 Solar Panel 620W

AED 350.00
In stock
Product Model
LR7-72HGD-620M
    • Longi HiMo7 LR7-72HGD-620M Series Solar Panels offers excellent outdoor performance and is suitable for ultra large power plants. They are manufactured with Industry leading advanced module technology using M10 Gallium Doped Wafer, smart soldering and 9-Busbar Half cut cell.
    Main Features

    1) Advanced Module technology delivers superior module efficiency M10-Gallium Doped Wafer, Smart soldering, 9-Bus Bar half Cut Cell.
    2) Based on M10-182mm wafer, best choice for Ultra Large Power plants.
    3) Excellent outdoor power generation performance.
    4) High Module quality ensures long term reliability
    5) 3.2mm Coated Tempered single glass
    More Information
    Technical specification
    1. High-performance PV modules for utility power plants
    2. Advanced HPDC cell technology delivers superior module efficiency and power
    3. High bifaciality and excellent power temperature coefficient achieves high energy yield
    4. LONGi lifecycle quality ensures long-term performance
    Mechanical Parameters
    Cell Orientation 144 (6×24)
    Junction Box IP68, three diodes
    Output Cable 4mm², +400, -200mm/±1400mm
    length can be customized
    Glass Dual glass, 2.0+2.0mm semi-tempered glass
    Frame Anodized aluminum alloy frame
    Weight 32.5kg
    Dimension 2382×1134×30mm
    Packaging 36pcs per pallet / 144pcs per 20’GP / 720pcs per 40’HC
    Model Product
    LR7-72HGD-620M
    Module type
    		 LR7-72HGD-620M
    Testing Condition
    		 STC        NOCT
    Max Power (Pmax/W)
    		         620          472.0
    Open Circuit Voltage (Voc/V)
    		 52.77       50.15
    Short Circuit Current (Isc/A)
    		  14.85       11.92
    Voltage at Max Power (Vamp/V)
    		 44.33       42.13
    Current  at Max Power (Imp/A)
    		 13.99      11.21
    Module Efficiency(%)
    		 23.0
    Operating Parameters

    Operational Temp
    		  -40°C ~ +85°C
    Power Output Tolerance
    		  0~+3%
    Max system volage
    		  DC1500V (IEC/UL)
    Max Series Fuse rating
    		 30A
    Nominal Operating Cell Temp
    		  45±2°C
    Protectional Class
    		  Class II
    Bifaciality 80±5%
    Fire Rating

     UL type 29
    IEC Class C
    Mechanical Loading
    Front Side Maximum Static Loading 5400Pa
    Rear Side Maximum Static Loading 2400Pa
    Hailstone Test 25mm Hailstone at the speed of 23m/s
    Temperature Ratings (STC)
    Temperature Coefficient of Isc +0.045%/℃
    Temperature Coefficient of Voc -0.230%/℃
    Temperature Coefficient of Pmax -0.280%/℃

    Electrical characteristics with different rear side power gain (reference to 615W front)
    Pmax /W Voc/V Isc /A Vmp/V Imp /A Pmax gain
    646 52.66 15.51 44.22 14.60 5%
    677 52.66 16.25 44.22 15.30 10%
    709 52.76 16.98 44.32 15.99 15%
    740 52.76 17.72 44.32 16.69 20%
    770 52.76 18.46 44.32 17.38 25%


    Disclaimer
    1. Astel Digicom Electronics reserves the right to change, modify specifications without prior notice.
    2. All pictures are for illustrative purposes only. Actual product may be different in color and size, which may appear in product specifications.
    3. Every effort is made to provide accurate information at the time of publishing, however Astel Digicom Electronics LLC is not responsible for
    any loss, directly or indirectly caused by any error in publishing.
    4. E&OE (Errors and Omissions are excepted)
    5. Longi is registered trade mark of Longi, China. Longi  registered office No 8369, Shengyuan Road, Xi'an Economic and Technological Development Zone, Xi'an, China
    6. Specifications included in this datasheet are subject to change without notice . Longi reserves the right of final interpretation.
