Growatt Lithium Ion Battery LiFEPo4 Hope 5.0L B1

AED 2,475.00
In stock
Product Model
Hope 5.0L B1
Growatt Hope 5.0L-B1
1) Compact size and easy installation
2) High energy density and efficiency
3) Excellent safety of LiFePO4 battery
4) External touch display screen optional
5) DoD up to 98%

Growatt Hope 5.0L-B1
1) Compact size and easy installation
2) High energy density and efficiency
3) Excellent safety of LiFePO4 battery
4) External touch display screen optional
5) DoD up to 98%

More Information
Technical specification

Datasheet Hope 5.0L-B1
Battery data
Nominal voltage 51.2V
Rated capacity 5.12kWh
Usable capacity 5.0kWh
Operating voltage 40 ~ 58.4V
Max. discharging current 100A
Peak discharging current 250A/150ms
Max charging current 100A
General data
Dimension (W/D/H) 440/480/130.5mm
Weight 43±2Kg
IP protection IP20
Charge temperature 0°C~+55°C
Discharge temperature -20°C~+55°C
Features
DOD 98%
Cycle life >6000 (25°C, 0.2C,)
Parallel connection Max.48 packs
Communication port CAN/RS485
Warranty 5 Years
  CE(EMC),UN 38.3, MSDS, ROHS
