main product photo

Jinko Solar Panel 590W Bifacial JKM590N72HL4BDV

AED 260.00
In stock
Product Model
JKM590N72HL4BDV

    • Main Features

     1) N-type modules with Tunnel Oxide Passivating Contacts (TOPcon) technology offer lower LID/LeTID degradation and better low light performance.
    2) N-type modules with JinkoSolar's HOT 3.0 technology offer better reliability and efficiency.
    3) Dual-sided power generation gain increases with backside exposure to light, significantly reducing LCOE.
    4) Better light trapping and current collection to improve module power output and reliability.
    5)Minimizes the chance of degradation caused by PID phenomena through optimization of cell production technology and material control.


    Main Features

     1) N-type modules with Tunnel Oxide Passivating Contacts (TOPcon) technology offer lower LID/LeTID degradation and better low light performance.
    2) N-type modules with JinkoSolar's HOT 3.0 technology offer better reliability and efficiency.
    3) Dual-sided power generation gain increases with backside exposure to light, significantly reducing LCOE.
    4)Certified to withstand:
             5400 Pa front side max static test load
             2400 Pa rear side max static test load
    5) Better light trapping and current collection to improve module power output and reliability.
    6)Minimizes the chance of degradation caused by PID phenomena through optimization of cell production technology and material control.

    More Information
    Technical specification

     Mechanical Characteristics
     Cell Type       N- type Mono-crystalline
     No. of cells       144（72×2）
     Dimensions       2278×1134×30 mm
     Weight       31.0 kg
     Front Glass       2.0 mm, Anti-reflection Coating
     Back Glass       2.0 mm, Heat Strengthened Glass
     Frame       Anodized Aluminium Alloy
     Junction Box      IP68 Rated
     Protection Class       Class II
    IEC Fire Type Class C
    Connector Type JK03M / JK03M2 / Others*
    Output Cables
    (Including Connector)    		 4.0 mm2
    (+): 400 mm , (-): 200 mm or Customized Length
    Packaging Configuration
    Pallet Dimentions 2338×1140×1251mm
    Packing Detail
    (Two pallets = One stack)    		 36 pcs/pallets, 72 pcs/stack,
    720 pcs/ 40'HQ Container
    Specifications (STC)
    Maximum Power - Pmax [Wp] 590
    Maximum Power Voltage - Vmp [V] 44.17
    Maximum Power Current - Imp [A] 13.36
    Open-circuit Voltage - Voc [V] 52.90
    Short-circuit Current - Isc [A] 14.07
    Module Efficiency STC [%] 22.84
    Power Tolerance 0 ~ + 3 %
    Temperature Coefficients of Pmax -0.29 %/°C
    Temperature Coefficients of Voc -0.25 %/°C
    Temperature Coefficients of Isc 0.045 %/°C
    Application Conditions
    Operating Temperature -40 °C ~ +70 °C
    Maximum System Voltage 1500 VDC (IEC)
    Maximum Series Fuse Rating 30 A
    Bifaciality Coefficient φVoc: 98±5 %, φIsc: 80±5 %, φPmax: 80±5 %


    Disclaimer
    1. Astel Digicom Electronics reserves the right to change, modify specifications without prior notice.
    2. All pictures are for illustrative purposes only. Actual product may be different in color and size, which may appear in product specifications.
    3. Every effort is made to provide accurate information at the time of publishing, however Astel Digicom Electronics LLC is not responsible for
    any loss, directly or indirectly caused by any error in publishing.
    4. E&OE (Errors and Omissions are excepted)
    5. Jinko Solar is registered trade mark of Jinko Solar Company, China.
    6. Specifications included in this datasheet are subject to change without notice . Jinko Solar reserves the right of final interpretation.
