main product photo

Growatt SPH 10000TL-HU 10kW Hybrid Solar Inverter

AED 0.00
In stock
Product Model
SPH 10000TL-HU
    • Growatt SPH 10000TL-HU is a high-performance single-phase hybrid inverter designed for residential and commercial solar energy systems. It features 3 MPPTs, 97.5% peak efficiency, UPS-level backup under 10ms, lithium and lead-acid battery compatibility, and IP65-rated protection for reliable operation in demanding environments.
     Key Features and Functionality:
    • UPS function, 10ms transition
    • 1.5 DC/AC Ratio with 3 MPPTs
    • Support Smart Load Function
    • Up to 200A charging/discharging current
    • Support DC-coupled, AC- coupled, and AC-retrofit applications
    • Type II Surge protection for DC and AC sides
    • Support Charge from the generator
    • Support form a 400V three-phase system
    • Support up to units in parallel
    More Information
    Technical specification

    Datasheet SPH 10000TL-HU
    Input data (DC)
    Max. recommended PV power (for module STC) 15000W
    Max. input power for single MPPT 10000W
    Max. DC voltage 525V
    Start voltage 150V
    MPP voltage range 150V-450V/370V
    No. of MPP trackers 3
    No. of PV strings per MPP tracker 2
    Max. input current per MPP tracker 22A
    Max. short-circuit current per MPP tracker 28A
    AC input data (AC)
    Nominal AC input power 10000W
    Nominal input voltage 230V
    Nominal input current 43.5A
    Max. grid passthrough current 62.5A
    Max. generator input power 10000W
    Output data (AC)
    AC nominal power 10000W
    Max. AC apparent power 10000VA
    Nominal AC voltage (range*) 220V/230V/240V
    AC grid frequency (range*) 50Hz/60Hz
    Max. output current 50A
    Adjustable power factor 0.8leading...0.8lagging
    THDi <3%
    AC grid connection type Single phase
    Battery data (DC)
    Battery voltage range 40~60V
    Max charging and discharging current 200A
    Continuous charging and discharging power 10000W
    Type of battery Lithium /Lead-acid
    Backup power (AC)
    AC nominal output power 10000W
    Nominal AC output voltage 220V/230V/240V
    Nominal AC output frequency 50/60Hz
    Switch time <10ms
    Efficiency
    Peak. efficiency 97.50%
    CEC welghted efficiency 96.7%
    MPPT efficiency ≥99.5%
    Protection devices
    PV switch Yes
    AC over current protection Yes
    AC over voltage protection Yes
    Ground fault monitoring Yes
    Grid monitoring Yes
    Anti-islanding protection Yes
    Residual-current monitoring unit Yes
    Insulation resistance monitoring Yes
    AFCI protection Yes
    Surge protection DC Type II / AC Type II
    General data
    Max stackable number 6
    Dimensions (W / H / D) 440/883/254mm
    Weight 48.84kg
    Operating temperature range –25°C ... +60°C(with derating above 45°C)
    Noise emission (typical) ≤ 30 dB(A)
    Self-Consumption < 60 W
    Topology Tranformerless
    Cooling Smart cooling
    Protection degree IP65
    Relative humidity 0~100%
    Altitude 2000m
    DC connection Quick Connector
    Display LCD
    Interfaces: RS485/CAN/USB Yes
    Communication WIFI/4G cellular (Opt)
    Warranty (5/10 years) Yes/Opt
      CE, UKCA, G99, NRS097
