Growatt SPF 6000 ES-H 6kW Hybrid Solar Inverter

AED 0.00
In stock
Product Model
SPF6000ES-H
Growatt SPF 6000 ES-H is a high-performance off-grid and hybrid inverter designed for efficient solar energy management. It features dual MPPT trackers, 8000W maximum PV input, pure sine wave output, and support for lithium and lead-acid batteries. With parallel support for up to 6 units, smart load functionality, and reliable operation in demanding environments, it is ideal for residential and commercial solar systems.

Key Features and Functionality:

  • Plug-and-Play terminal for PV port
  • Dual MPP trackers
  • Maximum PV input voltage up to 500VDC
  • Configurable grid or solar input priority
  • Parallel for scalability
  • Dust-proof filter for a harsh environment
  • Two AC input terminals with integrated transfer switch
  • Multiple off-grid & hybrid operation modes selectable
More Information
Technical specification

Datasheet SPF6000 ES-H
Battery Voltage 48VDC
Battery Type Lithium/Lead-acid
Inverter Output
Rated Power 6000VA/6000W
Parallel Capability Yes, 6 units maximum
AC Voltage Regulation
(Battery Mode)
230VAC ± 5% @ 50/60Hz
Surge Power 12000VA
Efficiency (Peak) 93%
Waveform Pure sine wave
Transfer Time 10ms typical,20ms Max
Grid Output (AC)
Nominal output voltage 230VAC
Output voltage range 195.5-253VAC,184-264.5VAC, 184-264.5VAC (selectable)
  27A
  >0.99
Solar Charger
Maximum PV Array Power 8000W
MPPT Range @ Operating Voltage 120VDC ~ 450VDC
Number of Independent MPP Trackers/
Strings Per MPP Tracker
2/1
Max. input current per MPP tracker 16A
Maximum PV Array Open
Circuit Voltage
500VDC
Maximum Solar Charge Current 100A
AC Charger
Charge Current 80A
AC Input Voltage 230VAC
Selectable Voltage Range 170-280 VAC (For Personal Computers); 90-280 VAC (For Home Appliances)
Frequency Range 50Hz/60Hz (Auto sensing)
Physical
Protection Degree IP20
Dimension (W/H/D) 460/395/132mm
Net Weight (kgs) 13.5
Operating Environment
Humidity 5% to 95% Relative Humidity(Non-condensing)
Altitude <2000m
Operating Temperature 0°C - 55°C
Storage Temperature -15°C - 60°C
