Growatt Hybrid Inverter 12KW SPE 12000 ES

AED 3,100.00
In stock
Product Model
SPE12000ES
Hybrid solar inverter
1) Dual MPP trackers
2) Maximum PV input voltage up to 550VDC
3) Two AC input terminals with integrated transfer switch
4) Featuring grid-tied function for peak shaving
5) Support parallel operation for capacity expansion up to 108kW.
6) Dual outputs for smart load management

Hybrid solar inverter
1) Dual MPP trackers
2) Maximum PV input voltage up to 550VDC
3) Two AC input terminals with integrated transfer switch
4) Featuring grid-tied function for peak shaving
5) Support parallel operation for capacity expansion up to 108kW.
6) Dual outputs for smart load management

More Information
Technical specification

Datasheet SPE 8000 ES SPE 10000 ES SPE 12000 ES
Input data (DC)
Max. recommended PV power
(for module STC)
10000W 12500W 15000W
Max. DC voltage 550V  550V 550V
Start voltage 120V  120V 120
MPP voltage range 60-480V  60V-480V 60V-480V
No. of MPP trackers  2 2
No. of PV strings per MPP tracker  1 1  1
Max. input current per MPP tracker 27A 27A 27A
Output data (AC)
AC nominal power 8000W 10000W 12000W
Max. AC apparent power 8000VA 10000VA 12000VA
Nominal AC voltage  230V 230V 230V
AC grid frequency  50/60Hz 50/60Hz  50/60 Hz
Output current 34.8A 43.5A 52.2A
Adjustable power factor   0.8leading...0.8lagging
THDi  <5% < 5%
Max. conversion efficiency (PV/AC)  96.5% 96.5% 96.5%
European efficiency @ vnominal (PV/AC)  95.5% 95.5% 95.5%
Battery data (DC)
Nominal DC voltage  48V 48V 48V
Max charging and discharging current 190A/200A 220A/240A 250A/280A
Type of battery Lithium Lead Acid  Lithium/Lead-acid Lithium Lead Acid
Backup power (AC)
AC nominal output power 8000W 10000W 12000W
Nominal AC output voltage   230V  230V
Nominal AC output frequency   50/60Hz 50/60 Hz
Switch time <20ms@single <30ms@parallel  <20ms@Single
<30ms@Parallel

<20ms@single <30ms@Parallel

Efficiency
Peak. efficiency 96.5%
European efficiency 95.5%
General data
Dimensions (W / H / D) 550/465/150mm
Weight 21.5kg
Operating temperature range –10°C ... +50°C
Noise emission (typical) <75dB
Self-consumption < 75W
Topology Tranformerless
Cooling DC fan
Protection degree IP20
Relative humidity 5%~95% non-condensing
Altitude <2000m
Communication WiFi/4G
CE, NRS097
