Fujikura Splicing Machine Core Sense FSM-41S Made in Japan

AED 8,500.00
In stock
Product Model
FSM41S
FTTH Splice Machine from Fujikura Global leader in Arc Fusion Splice Technology Light weight and compact FSM-41S has long battery life
Supports 250um, 900 um 2mm, 3mm, and drop cable fiber holders. Ruggedised transit case /work station


Main Features
1) The worlds smallest and Light Weight fusion Splice Machine
2) Light weight and compact FSM-41S has long battery life
3) Splice Machine from Fujikura Global leader in Arc Fusion Splice Technology
4) Average single mode splice loss of 0.018 dB
5) High Contrast 11 cm display
6) Compatible with Fuse Connect Fuse Splice on connectors
7) Supports 250um, 900 um 2mm, 3mm, and drop cable fiber holders.
8) Ruggedised transit case /work station

More Information
Technical specification

Technical specifications:

Parameters Fujikura FSM-41S Made in Japan
Applicable fibers
Single / SMF (G.652/657), MMF (G.651), DSF (G.653), NZDSF (G.655)
Cladding dia./ Sheathe dia.
125 µm / 160µm to 3mm by fiber holder system
Cleave length
5mm to 13mm
Splice mode / heating mode
Total 100 splice modes / 30 heating modes
Typical splice loss
0.05dB (SM), 0.02dB (MM), 0.08dB (DS) and 0.08dB (NZDS) Measured by cut-back method relevant to ITU-T and IEC standards.
Splice time / tube heating time
Typical 15sec with SM / Typical 30sec with FP-03(60mm) sleeve
Splice result storage
Last 2000 splices
Viewing methods / magnification
2 axis CMOS camera with 4.47” color LCD. 100X magnification.
Tension test
1.96 to 2.25N
Applicable protection sleeve
60mm, 40mm and Fujikura micro sleeves
No. of splice / heating per battery full charge
Typical 100 cycles with BTR-10
Electrode life
3000 splices
Size / weight
121W x 162D x 57H mm / 776g (including battery)
Operating condition
Altitude : 0 to 3,660m above sea level, Wind : 15m/sec Temperature : -10 to 50deg C, Humidity : 0 to 95%RH, non-dew
Other features
PC software upgrade / data management
Resistance features
Shock resistance : 76cm (30inch) bottom surface drop*1 Dust resistance : Exposure to dust (0.1 to 500µm dia. Alumina Silicate).*1 Rain resistance : H=10mm/hr for 10min*1
