ASTEL ONU-6112-XXX Fiber Optic Node for CATV Distribution

AED 525.00
In stock
Product Model
ONU-6112-XX

    • ASTEL Fiber Optic Node ONU-6112-XXX is a high-performance optical receiver node designed for CATV and fiber optic RF distribution networks. Equipped with four RF outputs, it uses an optical hybrid module, PIN photodiode and GaAs amplifiers to deliver stable optical-to-RF signal conversion with high gain and low distortion.
    The node supports single-mode fiber with SC/APC connectivity, an optical wavelength range of 1100–1600nm and RF frequencies from 45–862MHz. It features microprocessor-controlled operation, LED parameter monitoring, automatic gain control (AGC) and electronic attenuation adjustment. Available with mains and line-powering options, it is suitable for professional CATV and optical distribution installations.

    Key Features

    • Product series: ONU-6112-XXX

    • Product model listed: ONU-6112-XX

    • Four RF outputs

    • High-response PIN photodiode

    • Optical hybrid module and hybrid IC amplifiers

    • GaAs amplifier for high gain and low distortion

    • Microprocessor-controlled operation

    • LED display for operating parameters

    • Optimized Automatic Gain Control (AGC)

    • Single-mode optical fiber compatibility

    • SC/APC optical connector

    • Optical wavelength: 1100–1600nm

    • Optical receive power: -9 to +2dBm

    • Optical return loss: greater than 45dB

    • RF frequency range: 45–862MHz

    • RF frequency flatness: ±0.75dB

    • Rated RF output level: ≥108dBμV

    • Maximum RF output level: ≥112dBμV

    • RF output impedance: 75 Ohms

    • RF output return loss: ≥14dB

    • Carrier-to-noise ratio (C/N): ≥51dB at -2dBm optical input

    • Composite Triple Beat (CTB): ≥65dB

    • Composite Second Order (CSO): ≥60dB

    • Electronic equalization adjustment: 0–10dB

    • Electronic attenuation adjustment: 0–20dB

    • Power options: AC 150–265V or AC 35–90V

    • Power consumption: ≤30VA

    • Operating temperature: -40°C to +60°C

    • Dimensions: 240 × 240 × 150mm

    • Suitable for CATV optical reception and RF distribution systems



    More Information
    Technical specification

    Specification:

    Parameter Unit Values
    Optical Parameter
    Receive Optical Power dBm -9 ~ +2
    Return Loss dB >45
    Optical Wavelength nm 1100 ~ 1600
    Connector Type   SC/APC
    Fiber Type   Single Mode
    Circuit Performance
    C/N (Output 108 dBμV) dB ≥ 51（-2dBm Input）
    CTB (Output 108 dBμV) dB ≥ 65
    CSO (Output 108 dBμV) dB ≥ 60
    RF Performance
    Frequency Range MHz 45 ~862
    Flatness in Band dB ±0.75
    Rated Output Level dBμV ≥ 108
    Max Output Level dBμV ≥ 112
    Output Return Loss dB ≥14
    Output Impedance Ω 75
    Electronic Control EQ Range dB 0～10
    Electronic Control ATT Range dBμV 0～20
    General Parameter
    Supply Voltage V A：AC（150~265）V；B：AC（35~90）V
    Operating Temperature °C -40~60
    Consumption VA ≤ 30
    Dimension mm 240（L）╳ 240（W）╳ 150（H）
     Disclaimer

    Astel Digicom Electronics reserves the right to change, modify specifications without prior notice.
    All pictures are for illustrative purposes only. Actual product may be different in color and size, which may appear in product specifications.
    Every effort is made to provide accurate information at the time of publishing, however Astel Digicom Electronics LLC is not responsible for
    any loss, directly or indirectly caused by any error in publishing.
    E&OE (Errors and Omissions are excepted).
