Deye 16KW Single Phase Hybrid Inverter is a high-performance solar energy solution designed for residential and commercial applications. It supports lithium-ion and lead-acid batteries, AC coupling for retrofit solar systems, and parallel operation up to 16 units for flexible on-grid and off-grid installations. Featuring IP65 protection, intelligent air cooling, advanced battery management, and up to 97.6% efficiency, it delivers reliable and efficient solar power management.
DC Polarity Reverse Connection Protection, AC Output Overcurrent Protection, Thermal Protection, AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring, Overvoltage Load Drop Protection, Ground Fault Current Monitoring, Arc Fault Circuit Interrupter (optional), Power Network Monitoring, Island Protection Monitoring, Earth Fault Detection, DC Input Switch, DC Terminal Insulation Impedance Monitoring, Residual Current (RCD) Detection, Surge protection level
Surge Protection Level
TYPE II(DC), TYPE II(AC)
Interface
Communication Interface
RS485/RS232/CAN
Monitor Mode
GPRS/WIFI/Bluetooth/4G/LAN(optional)
General Data
Operating Temperature Range (°C)
-40 to +60°C, >45°C Derating
Permissible Ambient Humidity
0-100%
Permissible Altitude
2000m
Noise (dB)
<50
Ingress Protection(IP) Rating
IP 65
Inverter Topology
Non-Isolated
Over Voltage Category
OVC II(DC), OVC III(AC)
Cabinet Size (WxHxD mm)
464×763×282 (Excluding Connectors and Brackets)
Weight (kg)
52
Type of Cooling
Intelligent Air Cooling
Warranty
5 Years/10 Years
The Warranty Period depends on the Final Installation Site of the Inverter. More Info: Please Refer to the Warranty Policy
Disclaimer 1. Astel Digicom Electronics reserves the right to change or modify specifications without prior notice. 2. All pictures are for illustrative purposes only. Actual product may be different in color and size, which may appear in product specifications. 3. Every effort is made to provide accurate information at the time of publishing, Astel Digicom Electronics LLC is not responsible for any loss, directly or indirectly, caused by any error in publishing. 4. E&OE (Errors and Omissions are excepted)5. Deye is registered trademark of Ningbo Deye Inverter Technology Co., Ltd., Shenzhen, China.
