main product photo

Ramcro KNX 2Pair Cable for Home Automation R1217

AED 625.00
In stock
Product Model
R1217
    • Product Description:
    KNX is a standardised (EN 50090, ISO/IEC 14543), OSI based network communications protocol for intelligent buildings. KNX is the successor to, and convergence of, three previous standard: the European Home Systems Protocol (EHS), BatiBUS, and European Installation Bus (EIB or InstaBUS)

    Product Description:
    KNX is a standardised (EN 50090, ISO/IEC 14543), OSI based network communications protocol for intelligent buildings. KNX is the successor to, and convergence of, three previous standard: the European Home Systems Protocol (EHS), BatiBUS, and European Installation Bus (EIB or InstaBUS)

    More Information
    Technical specification

    SPECIFICATIONS:

    Construction
    Formation 1 Quad   Nominal
    Section 0.8 mm Unit Value
    Conductor Plain annealed copper wire, Solid  mm 0.8
    Insulation Polyetilene - PE mm 1.4
    Colour Code Black, Red, White, Yellow
    Individual Screen N.A.
    Wrapping film thickness at least 1 layer of plastic tape 0,023 mm mm  0.023
    Collective Screen thickness 0.026 mm Aluminium / PETP tape over tinned copper drain wire mm  0.026
    Inner Sheath N.A.
    Armour N.A.
    Outer Sheath Polyvinyl chloride - PVC - Green RAL 6018 mm  5.7
    Cable Printing RAMCRO ITALY R1217 EIB CABLE 4x0.8mm SCREENED PVC - SAM4108HIADHRB + "sett.prod/18" + Batch n° + Meter Marking
    Technical Data & Standard References
    Fire Propagation:
    - Test on single cable IEC 60332-1
    - Test on bunched cables IEC 60332-3 Type of Cable: DATA LAN KNX - EIB Cable
    Limiting Oxygen Index (LOI) (min 30%) Low Voltage Directive 2014/35/UE
    Smoke Density IEC 61034 Other References:
    Amount of halogen acid gas IEC 60754-1 (max 15%)
    Acidity (ph value) and conductivity IEC 60754-2
    Sunlight resistance UL 1581 section 1200
    Notes
    Electrical & Mechanical Data
    Conductor Cross-section Nom. 0.8 mm Temperature Range:
    DC Resistance per core at 20° C max Ω/km 37 During Operation ° C -30°C up to 80°C
    Insulation Resistance at 20° C min MΩ*km 1000 During Installation ° C -30°C up to 80°C
    Nominal Mutual Capacitance max pF/m 100 Min. Bending Radius mm 8 x cable diameter
    Inductance max mH/km 1 Max Pulling Tension N/mm2 99
    Test Voltage - Core/Core V 2000 Weight Approx kg/km 58
    Test Voltage - Core/Screen V 2000 Put up length mt 305
    Operating Voltage V 300

    Disclaimer:
    Astel Digicom Electronics reserves the right to change, modify specifications without prior notice.
    All pictures are for illustrative purposes only. Actual products may be different in color and size that may
    appear in product specifications.
    Every effort is made to provide accurate information at the time of publishing, however, Astel Digicom
    Electronics LLC is not responsible for
    any loss, directly or indirectly caused by any error in publishing.
    Ramcro is registered trademark of Ramcro s.p.a., Italy.
    E&OE (Errors and Omissions are excepted)
