Product Description:KNX is a standardised (EN 50090, ISO/IEC 14543), OSI based network communications protocol for intelligent buildings. KNX is the successor to, and convergence of, three previous standard: the European Home Systems Protocol (EHS), BatiBUS, and European Installation Bus (EIB or InstaBUS)
Product Description:KNX is a standardized (EN 50090, ISO/IEC 14543), OSI based network communications protocol for intelligent buildings. KNX is the successor to, and convergence of, three previous standard: the European Home Systems Protocol (EHS), BatiBUS, and European Installation Bus (EIB or InstaBUS)
Amount of halogen acc. to IEC 60754-1 & EN 50267-1
ZERO
Acidity (ph value) and conductivity
IEC 60754-2
Sunlight resistance
UL 1581 section 1200
Notes
Electrical & Mechanical Data
Conductor Cross-section
Nom.
0.8 mm
Temperature Range:
DC Resistance per core at 20° C
max Ω/km
37
During Operation
° C
-30°C up to 80°C
Insulation Resistance at 20° C
min MΩ*km
5000
During Installation
° C
-30°C up to 80°C
Nominal Mutual Capacitance
max pF/m
100
Min. Bending Radius
mm
8 x cable diameter
Inductance
max mH/km
1
Max Pulling Tension
N/mm2
50
Test Voltage - Core/Core
V
2000
Weight Approx
kg/km
40
Test Voltage - Core/Screen
V
2000
Put up length
mt
305
Operating Voltage
V
300
